Product no 1000902205
Model VIGI C340(2.8mm)
Brand TP-LINK Technologies
EAN 4897098688618
Weight 0.46 kg
Produktbeskrivelse | TP-Link VIGI C340 V1 - netværksovervågningskamera - kugle |
Enhedstype | Netværksovervågningskamera - fast - kugle - udendørs - vejrbestandig |
Audio | Ja: indbygget højttaler, indbygget mikrofon |
Dimensioner (B x D x H) | 7 cm x 17.4 cm x 7.8 cm |
Vægt | 195 g |
Connectivity teknologi | Med ledning |
Kamera | Farve - Dag/nat |
Maksimum opløsning | 2560 x 1440 |
Billedhastighed (maks.) | 30 frames pr. sekund |
Bevægelsesdetektion | Ja |
Billedsensortype | CMOS - 1/3" |
Brændviddekontrol | Fast brændvidde |
Brændvidde | 2.8 mm |
Objektivmontering | M12 montering |
Objektiv Iris | F/1.6 |
Interface | Ethernet 10Base-T/100Base-TX |
Spænding | DC 12 V |
Egenskaber | Backlight Compensation (BLC), IR-filter, skarphedskontrol, mætningskontrol, lysstyrkekontrol, kontrastkontrol, spejlbillede, ONVIF support, Privacy Mask Function, Digital Wide Dynamic Range (D-WDR), Live View-kontrol, programmérbar hvidbalance, Detektion af kamerapilleri, Smart IR, nulstillingsknap, kodeordsbeskyttelse, 2-vejs stemmekommunikation, Region of Interest (ROI), eksponeringskontrol, plastikkabinet, digest-autentificering, Line Crossing Detection, IP-adressefiltrering, 3D digital støjreduktion (DNR), HTTP-kryptering, menneskedetektion, Smart Detection, omgående notifikation, objekt trænger ind på område-detektion, MiMo WiFi-konnektivitet, Active Defense, adgangskodenulstilling via e-mail, 2 videostreams, videomanipulationsdetektion |
Producentgaranti | 3 års garanti |
Miljømæssige parametre (operativ) | -30 °C - 60 °C |
General | |
---|---|
Audio Support | Yes: built-in speaker, built-in microphone |
Connectivity Technology | Wired |
Depth | 17.4 cm |
Device Type | Network surveillance camera |
Form Factor | Bullet |
Height | 7.8 cm |
Weight | 195 g |
Width | 7 cm |
Camera | |
Digital Video Capture Resolution | 640 x 480, 320 x 240, 352 x 288, 1920 x 1080, 2304 x 1296, 2560 x 1440, 2048 x 1280 |
Digital Video Format | H.264, H.265, H.265+, H.264+ |
Features | Backlight Compensation (BLC), IR filter, sharpness control, saturation control, brightness control, contrast control, image mirror, ONVIF support, Privacy Mask Function, Digital Wide Dynamic Range (D-WDR), Live View Control, programmable white balanc |
Frame Rate (max) | 30 frames per second |
Infrared Distance | 30 m |
Infrared LEDs | Yes |
Max Digital Video Resolution | 2560 x 1440 |
Motion Detection | Yes |
Type | Color - Day&Night - fixed - outdoor - weatherproof |
Image Sensor | |
Type | CMOS 1/3" |
Lens Construction | |
Diagonal Field of View (degree) | 122 |
Focal Length | 2.8 mm |
Focus Adjustment | Focus free |
Horizontal Field of View (degree) | 102 |
Lens Iris | F/1.6 |
Type | M12 mount - fixed focal |
Vertical Field of View (degree) | 55 |
Interfaces | |
Network Interface | Ethernet 10Base-T/100Base-TX |
Network Protocols | DHCP, DNS, HTTP, NTP, TCP/IP, UDP/IP, ICMP, RTSP, HTTPS, UPnP, TLS, SSL |
Expansion / Connectivity | |
Ports | LAN - RJ-45 |
Supported Memory Cards | microSD Card |
Miscellaneous | |
Compliant Standards | VCCI, BSMI, RoHS, NTRA, IP66, KC, RCM, IEEE 802.3af, IEEE 802.3at |
Included Accessories | Mounting hardware, waterproof cable attachments |
Power | |
Power Requirements | DC 12 V |
Manufacturer Warranty | |
Service & Support | Limited warranty - 3 years |
Environmental Parameters | |
Max Operating Temperature | 60 °C |
Min Operating Temperature | -30 °C |
