Product no 996063324
Model USW-48-POE
Brand
Go to brand's website
EAN 0810010072146
Weight 5.7 kg
Produktbeskrivelse | Ubiquiti UniFi Switch USW-48-POE - switch - 48 porte - Administreret - monterbar på stativ |
Enhedstype | Switch - 48 porte - Administreret |
Pakningstype | Monterbar på stativ 1U |
Undertype | Gigabit Ethernet |
Porte | 48 x 10/100/1000 (32 PoE+) + 4 x Gigabit SFP |
Power Over Ethernet (PoE) | PoE+ |
PoE-budget | 195 W |
Præstation | Ikke-blokerende båndbredde: 18 Gbps<br>Omkoblingskapacitet: 36 Gbps<br>Videresendelseshastighed: 26.78 Mpps |
Egenskaber | Datatransport, Layer 2 switching, auto-uplink (auto MDI/MDI-X), portspejling, DPI, Jumbo Frames support, blæserløs, GVRP, Storm Control, sammenlægningstilstand, 12KV ESD Protector (kontaktafladning), 16KV ESD Protector (lufthulsafladning) |
Overensstemmelsesstandarder | IEEE 802.3af, IEEE 802.1x, IEEE 802.3at |
Effekt | AC 120/230 V (50/60 Hz) |
Dimensioner (B x D x H) | 44.24 cm x 28.5 cm x 4.37 cm |
Vægt | 4.52 kg |
Systemkrav | Apple MacOS, Linux, Microsoft Windows 7 / 8 / 10 |
Producentgaranti | 1 års garanti |
General | |
---|---|
Authentication Method | RADIUS |
Built-in Devices | 1.3" touch screen display |
Compliant Standards | IEEE 802.3af, IEEE 802.1x, IEEE 802.3at |
Device Type | Switch - 48 ports - managed |
Enclosure Type | Desktop, rack-mountable 1U |
Features | Flow control, layer 2 switching, auto-uplink (auto MDI/MDI-X), port mirroring, Deep Packet Inspection (DPI), Jumbo Frames support, fanless, Dynamic VLAN Support (GVRP), Storm Control, aggregation mode, 12KV ESD Protector (contact discharge), 16KV ESD |
Performance | Non-blocking bandwidth: 18 Gbps | Switching capacity: 36 Gbps | Forwarding rate: 26.78 Mpps |
PoE Budget | 195 W |
Ports | 48 x 10/100/1000 (32 PoE+) + 4 x Gigabit SFP |
Power Over Ethernet (PoE) | PoE+ |
Status Indicators | PoE, link/activity, link/activity/speed |
Subtype | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 32 x 1000Base-T RJ-45 PoE+ - 32 W | 16 x 1000Base-T RJ-45 | 4 x Gigabit LAN SFP |
Power | |
Power Consumption Operational | 45 Watt |
Power Device | Internal power supply |
Power Provided | 210 Watt |
Voltage Required | AC 120/230 V (50/60 Hz) |
Miscellaneous | |
Compliant Standards | IC, FCC, ETSI 300 019-1-4 |
Rack Mounting Kit | Included |
Software / System Requirements | |
OS Required | Apple MacOS, Linux, Microsoft Windows 7 / 8 / 10 |
Dimensions & Weight | |
Depth | 28.5 cm |
Height | 4.37 cm |
Weight | 4.52 kg |
Width | 44.24 cm |
Manufacturer Warranty | |
Service & Support | Limited warranty - 1 year |
Environmental Parameters | |
Humidity Range Operating | 10 - 90% (non-condensing) |
Max Operating Temperature | 40 °C |
Min Operating Temperature | -5 °C |
