Varenummer 991809003
Model ICUSB23208FD
Producent StarTech.com
EAN 0065030866705
Vægt 2.1 kg
Produktbeskrivelse | StarTech.com USB to Serial Hub - 8 Port - COM Port Retention - Rack Mount and Daisy Chainable - FTDI USB to RS232 Hub (ICUSB23208FD) - seriel adapter - USB 2.0 - RS-232 x 8 |
Enhedstype | Seriel adapter |
Model | Ekstern |
Grænseflade (bus) type | USB 2.0 |
Porte | RS-232 x 8 |
Dimensioner (B x D x H) | 12 cm x 43 cm x 4.5 cm |
Vægt | 1.4 kg |
Dataforbindelsesprotokol | RS-232 |
Farve | Sort |
Effekt | AC 120/230 V |
Systemkrav | Microsoft Windows 98 Second Edition, Microsoft Windows XP Embedded, Microsoft Windows Server 2003, Microsoft Windows CE 5.0, Microsoft Windows CE 4.2, Microsoft Windows Server 2008 R2, Linux 2.4.x eller nyere, Microsoft Windows CE 6.0, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows 2000/XP/Vista/7/8/8.1/10, Microsoft Windows Server 2019, kun Linux LTS-versioner, Apple MacOS X 10.6 - 10.15, Apple macOS 11.0, Apple macOS 12.0, Microsoft Windows 11, Apple macOS 13.0 |
Producentgaranti | 2 års garanti |
Generelt | |
---|---|
Enhedstype | Seriel adapter |
Grænseflade (bus) type | USB 2.0 |
Netværk | |
Dataforbindelsesprotokol | RS-232 |
Forbindelsesteknologi | Kabling |
Porte | RS-232 x 8 |
Statusindikatorer | Status |
Ekspansion / Konnektivitet | |
Interface | 8 x RS-232 - 9 pin D-Sub (DB-9) (han) | 1 x USB - 4 pin USB Type B |
Diverse | |
Farve | Sort |
Medfølgende ledninger | 1 x USB-kabel (ekstern) - 90 cm |
Overensstemmelsesstandarder | FCC, RoHS |
Udstyr inkluderet | 2 stativmonteringsbøjler, 4 x møtrikker, stativmonteringsskruer, DIN-skinnemonteringsskruer, 2 DIN skinnemonteringsbøjler, 4 spændeskiver, terminalblokprop, strømadapter |
Effekt | |
Nødvendig spænding | AC 120/230 V |
Strømforbrug ved drift | 36 Watt |
Programmer / Systemkrav | |
Med software | Drivers & Utilities |
OS nødvendig | Microsoft Windows 98 Second Edition, Microsoft Windows XP Embedded, Microsoft Windows Server 2003, Microsoft Windows CE 5.0, Microsoft Windows CE 4.2, Microsoft Windows Server 2008 R2, Linux 2.4.x eller nyere, Microsoft Windows CE 6.0, Microsoft Wind |
Mål og vægt | |
Bredde | 12 cm |
Dybde | 43 cm |
Højde | 4.5 cm |
Vægt | 1.4 kg |
Producentgaranti | |
Service & Support | Begrænset garanti - 2 år |
Miljømæssige parametre | |
Fugtighedsgrad ved brug | 20 - 80 % (ikke-kondenserende) |
Maks. driftstemperatur | 85 °C |
Min. driftstemperatur | -40 °C |
