Brother TD-4520DN Direct thermal
Ved at anvende direkte termisk printteknologi, får man nøjagtige billeder med høj billedskarphed. God til stort printbehov og til midlertidige labels med stregkoder.
-
Product no 994812296
Model TD4520DNXX1
Brand
Go to brand's websiteEAN 4977766798266
Weight 3.96 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | Brother TD-4520DN - etiketprinter - S/H - direkte termisk |
| Printertype | Etiketprinter - direkte termisk - S/H |
| Vægt | 2.08 kg |
| Maks. mediestørrelse | Rulle (11,8 cm) |
| Minimum Medie Størrelse (Almindelig) | 19 mm x 6.4 mm |
| Max. mediestørelse (brugerdefineret) | 118 mm x 3000 mm |
| Printerhastighed | Op til 152 mm/sek |
| Maks. opløsning (S og H) | 300 x 300 dpi |
| Grænseflade | USB 2.0, LAN, seriel |
| RAM installeret (maks.) | 256 MB SDRAM |
| Flash Hukommelse Installeret (Max) | 64 MB |
| Sprogsimulering | EPSON ESC/P, ZPL II, EPSON ESC/P Raster, Comtec Printer Control Language (CPCL) |
| Stregkoder | Kode 93, Industribrug 2 af 5, Kode 39, NW-7, GS1 DataBar, QR-kode, MaxiCode, Aztec-kode, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, MicroPDF417, Coadabar, Code 128, Postnet, PDF417, MSI-Plessey, Data Matrix, ITF, Micro QR kode, GS1-128, RSS |
| Medietype | Kvitteringspapir, listepapir, fortløbende mærkater, pressestempel skæreetikette, skilte, armbånd |
| Kompatible bånd | RD bånd |
| Skrifttyper | Brussels, Helsinki, Letter Gothic Bold, Gothic, Brougham |
| Egenskaber | Transmissiv mediesensor, reflekterende mediesensor, sensor til åbent dække, spejltryk |
| Netværk | Udskriftsserver |
| Printeregenskaber | Drop i-papirindføring, realtidsur |
| Systemkrav | Microsoft Windows 7, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Windows 8, Microsoft Windows Server 2012, Android 4.0.3 eller senere, Microsoft Windows Server 2012 R2, Windows 10, Apple iOS 8 eller senere, Microsoft Windows Server 2016 |
| Fås i farverne | Grå, hvid |
| Producentgaranti | 3 års garanti |
| Dimensioner (B x D x H) | 10.8 cm x 22.4 cm x 15.5 cm |
| General | |
|---|---|
| Enclosure Color | Gray, white |
| Printer Type | Label printer - direct thermal - monochrome |
| Printer | |
| Barcodes | Code 93, Industrial 2 of 5, Code 39, NW-7, GS1 DataBar, QR code, MaxiCode, Aztec code, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, MicroPDF417, Codabar, Code 128, Postnet, PDF417, MSI-Plessey, Data Matrix, ITF, Micro QR code, GS1-128, RSS |
| Connectivity Technology | Wired |
| Features | Transmissive media sensor, reflective media sensor, open cover sensor, mirror print |
| Fonts | Brussels, Helsinki, Letter Gothic Bold, Gothic, Brougham |
| Interface | USB 2.0, LAN, serial |
| Language Simulation | EPSON ESC/P, ZPL II, EPSON ESC/P Raster, Comtec Printer Control Language (CPCL) |
| Max Resolution (B&W) | 300 x 300 dpi |
| Print Speed | Up to 152 mm/sec |
| Printer Features | Drop-in paper loading, real time clock |
| RAM | |
| RAM Installed (Max) | 256 MB |
| Technology / Form Factor | SDRAM |
| Flash Memory | |
| Flash Memory | 64 MB |
| Media Handling | |
| Compatible Tapes | RD tape |
| Max Media Size | Roll (11.8 cm) |
| Max Media Size (Custom) | 118 mm x 3000 mm |
| Max Printing Width | 108 mm |
| Media Sizes | Roll (1.9 cm), Roll (11.8 cm) |
| Media Thickness Range | 0.058 mm - 0.279 mm |
| Media Type | Receipt paper, fanfold paper, continuous labels, die cut labels, tags, wristbands |
| Min Media Size (Custom) | 19 mm x 6.4 mm |
| Roll Core Diameter | 12.7 mm |
| Roll Maximum Outer Diameter | 127 mm |
| Networking | |
| Networking | Print server |
| Security Protocols & Features | 802.1x, EAP-TTLS, EAP-TLS, PEAP, EAP-FAST, EAP-MD5 |
| Expansion / Connectivity | |
| Connections | 1 x RS-232C | 1 x USB 2.0 | 1 x LAN - RJ-45 |
| Miscellaneous | |
| Cables Included | 1 x USB cable |
| Software / System Requirements | |
| OS Required | Microsoft Windows 7, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Windows 8, Microsoft Windows Server 2012, Android 4.0.3 or later, Microsoft Windows Server 2012 R2, Windows 10, Apple iOS 8 or later, Microsoft Windows Server 2016 |
| Software Included | Brother P-touch Editor |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Humidity Range Operating | 20 - 85% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 5 °C |
| Dimensions & Weight | |
| Depth | 22.4 cm |
| Height | 15.5 cm |
| Weight | 2.08 kg |
| Width | 10.8 cm |
Beskæringsfunktion
Ideel til at lave shipping-labels. Dit dokument i A4 scannes og stregkode-informationen bliver automatisk behandlet. Individuelle labels bliver så printet fra din TD-4520D.
Ukompliceret integration
Der er mange kommandosprog tilgængelige for at gøre integrationen så let som mulig. Herunder ZPL II emulation, Raster og CPCL emulation, der gør det muligt at integrere med ældre systemer.
Print fra din Windows-computer
Du kan let lave skræddersyede labels med Brothers P-touch Editor. Tilføj virksomhedens logo, eller symboler til hundredvis af indbyggede billeder, til de labels, du laver. For ikke at nævne, at du kan linke dine Excel-data for at printe store mængder af labels.
Netværksforbindelse
Forøg produktiviteten med denne professionelle labelprinter, der har simpel deling med den integrerede netværksport. Flere brugere kan dele labelprinteren fra forskellige lokationer.
