HPE Aruba 2930M 48G 1-Slot Switch 48-porte Gigabit
HPE Aruba 2930M 48G 1-Slot - Switch - L3 - Administreret - 44 x 10/100/1000 + 4 x combo Gigabit SFP - front til ryg-luftstrøm - monterbar på stativ
29 589,00DKK23 671,20DKK excl. VAT
Aruba 2930M-switchen er designet til kunder, der skaber digitale arbejdspladser, som er optimeret til mobile brugere med en integreret kablet og trådløs tilgang. Denne Layer 3 access switch er nem at implementere og administrere med avancerede sikkerheds- og netværksadministrationsværktøjer som Aruba ClearPass Policy Manager og Aruba AirWave. Med support fra cloud-baserede Aruba Central kan du hurtigt opsætte fjernkontorer med lidt eller ingen IT-support. En kraftfuld Aruba ProVision ASIC leverer ydeevne og værdi med understøttelse af de nyeste SDN-apps med fremtidssikret programmerbarhed til morgendagens applikationer. Højtydende modulær stacking for op til 10 switche giver enkelhed og skalerbarhed med en pay as you grow-tilgang. 2930M understøtter Dual Modular Power Supplies, op til 1440 watt PoE+, HPE Smart Rate (IEEE 802.3bz), robust QoS, RIP, Access OSPF routing, Tunnel Node, PIM, VRRP og IPv6 uden behov for softwarelicenser. Aruba 2930M Switch Series giver en praktisk og omkostningseffektiv access switch-løsning, der hurtigt kan sættes op med Zero Touch Deployment.
-
Product no 992512586
Model JL321A
Brand Hewlett Packard Ente
EAN 0190017071237
Weight 7.4 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | HPE Aruba 2930M 48G 1-Slot - switch - 48 porte - Administreret - monterbar på stativ |
| Enhedstype | Switch - 48 porte - L3 - Administreret - kan stables |
| Pakningstype | Front til ryg-luftstrøm monterbar på stativ 1U |
| Undertype | Gigabit Ethernet |
| Porte | 44 x 10/100/1000 + 4 x combo Gigabit SFP |
| Præstation | Kapacitet: 112 Mpps<br>Latens (10 Mbps): 98.5 µs<br>Latens (100 Mbps): 11.8 µs<br>Latens (1 Gbps): 3.1 µs<br>Latens (10 Gbps): 3.4 µs<br>Stablende båndbredde: 100 Gbps<br>Omkoblingskapacitet: 176 Gbps |
| Kapacitet | IPv4 indtastning i routing-tabel: 2000<br>IPv6 indtastning i routing-tabel: 1000<br>RIP ruter: 10000<br>Statiske ruter: 256<br>OSPF ruter: 200 |
| MAC adresse table størrelse | 32.768 indtastninger |
| Jumborammesupport | 9220 byte |
| Routingprotokol | OSPF, RIP, RIP-1, RIP-2, IGMPv2, IGMP, OSPFv2, statisk IP routing, IGMPv3, OSPFv3, statisk IPv4 routing, statisk IPv6 routing, RIPng, MLDv2, MLD, CIDR |
| Protokol til fjernadministration | SNMP 1, SNMP 2, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, SSH, SSH-2, CLI, XRMON |
| Egenskaber | Datatransport, DHCP-understøttelse, understøttet af BOOTP, VLAN-understøttet, IGMP snooping, DiffServ understøttet, IPv6 understøttet, SNTP-understøttet, sFlow, Quality of Service (QoS), DHCP server, STP Root Guard, Uni-Directional Link Detection (UDLD), Management Information Base (MIB), dynamisk ARP beskyttelse, DHCP beskyttelse, Dynamic VLAN Support (GVRP), Multiple VLAN Registration Protocol (MVRP), Class of Service (CoS), Type of Service (ToS), ICMP Router Discovery Protocol (IRDP), Virtual Extensible LAN (VXLAN) |
| Overensstemmelsesstandarder | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1AX |
| Effekt | AC 120/230 V (50/60 Hz) - strømforsyning ikke installeret |
| Dimensioner (B x D x H) | 44.25 cm x 32.43 cm x 4.39 cm |
| Vægt | 4.6 kg |
| Producentgaranti | Begrænset livtidsgaranti |
| General | |
|---|---|
| Authentication Method | RADIUS, PAP, CHAP, TACACS, TACACS+ |
| Capacity | IPv4 routing table entries: 2000 | IPv6 routing table entries: 1000 | RIP routes: 10000 | Static routes: 256 | OSPF routes: 200 |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1AX |
| Device Type | Switch - 48 ports - L3 - managed - stackable |
| Enclosure Type | Front to back airflow rack-mountable 1U |
| Encryption Algorithm | MD5, SSL |
| Features | Flow control, DHCP support, BOOTP support, VLAN support, IGMP snooping, DiffServ support, IPv6 support, SNTP support, sFlow, Quality of Service (QoS), DHCP server, STP Root Guard, Uni-Directional Link Detection (UDLD), Management Information Base (MI |
| Flash Memory | 4 GB |
| Jumbo Frame Support | 9220 bytes |
| MAC Address Table Size | 32768 entries |
| Performance | Throughput: 112 Mpps | Latency (10 Mbps): 98.5 µs | Latency (100 Mbps): 11.8 µs | Latency (1 Gbps): 3.1 µs | Latency (10 Gbps): 3.4 µs | Stacking bandwidth: 100 Gbps | Switching capacity: 176 Gbps |
| Ports | 44 x 10/100/1000 + 4 x combo Gigabit SFP |
| Processor | 1 x ARM Cortex-A9: 1.016 GHz |
| RAM | 1 GB DDR3 SDRAM |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, SSH, SSH-2, CLI, XRMON |
| Routing Protocol | OSPF, RIP, RIP-1, RIP-2, IGMPv2, IGMP, OSPFv2, static IP routing, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, RIPng, MLDv2, MLD, CIDR |
| Subtype | Gigabit Ethernet |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x Stacking Module slot | 1 (total) / 1 (free) x expansion slot |
| Interfaces | 44 x 1000Base-T RJ-45 | 4 x Gigabit LAN | 1 x serial (console) RJ-45 | 1 x USB Type B | 1 x management RJ-45 |
| Power | |
| 80 PLUS Certification | 80 PLUS Silver |
| Max Supported Qty | 2 |
| Power Device | Internal power supply (not installed) |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Miscellaneous | |
| Compliant Standards | CISPR 22 Class A, CISPR 24, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, ICES-003 Class A, UL 60950-1 Second Edition, CSA C22.2 No. 60950-1-07 Second Edition, |
| Dimensions & Weight | |
| Depth | 32.43 cm |
| Height | 4.39 cm |
| Weight | 4.6 kg |
| Width | 44.25 cm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | |
| Humidity Range Operating | 15 - 95% (non-condensing) |
| Humidity Range Storage | 90% (non-condensing) |
| Max Operating Temperature | 55 °C |
| Max Storage Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Min Storage Temperature | -40 °C |
Aruba 2930M 48G 1-slot Switch
The Aruba 2930M Switch Series is designed for digital workplaces optimized for mobile users. These powerful Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and cloud-based Aruba Central. Modular stacking, uplinks and power provide scalability and simplicity for enterprise edge, SMB and branch office networks. The 2930M delivers performance and value with support for static, RIP and Access OSPF routing, 10GbE and 40GbE uplinks, models with 24 ports of HPE Smart Rate multi-gigabit Ethernet, up to 1440W of PoE, robust QoS, and Dynamic Segmentation for unified and secure access.
Aruba Layer 3 switch series that is easy to deploy and manage with Aruba ClearPass Policy Manager and on-premise with Aruba Airwave.
Simplify with Zero Touch Provisioning and cloud-based Aruba Central support.
Scale with modular 10 chassis stacking and up to 1440W PoE.
Modular 10GbE and 40GbE uplinks and HPE Smart Rate multi-gigabit support.
Models with 24 ports of HPE Smart Rate with IEEE 802.3bz.
High Power PoE models deliver up to 60W of PoE per port.
High-Performance Layer 3 Access Switches
- The Aruba 2930M Switch Series provides performance, security, and ease of use for enterprise edge, SMB, and branch office networks.
- Optimized for the digital workplace with unified management tools such as Aruba ClearPass Policy Manager, Aruba Airwave and Aruba Central. Provides optimal configuration automatically when connected to Aruba access points for PoE priority, VLAN configuration, and rogue AP containment.
- Pay as you grow modular stacking (10 chassis) and modular 10GbE (SFP+) and 40GbE (QSFP+) uplinks. HPE Smart Rate multi-gigabit Ethernet models support high speed APs over existing cabling and upgradeable power supplies allow your network to quickly scale when more PoE is needed.
- Robust Layer 3 feature set includes Access OSPF, static and RIP routing, ACLs, Dynamic Segmentation, sFlow, IPv6 with no software licensing required.
- Designed with a power ProVision ASIC, the 2930M supports multiple programmatic interfaces, including REST APIs and Openflow 1.0 and 1.3, to enable automation of network operations, monitoring, and troubleshooting.
Performance and Power at the Edge
- The Aruba 2930M Switch Series is designed with a powerful Aruba ProVision ASIC, to enable the mobile campus with low latency, increased packet buffering, and adaptive power consumption.
- Increase performance with selectable queue configurations and associated memory buffering that meets your specific network application requirements.
- Plug and play with up to 10 chassis stacking allowing automated failover enhances network resiliency and RPS support delivers power redundancy.
- Supports hot swappable and redundant PoE power for wireless access points, cameras and phones and can easily scale to 1440W with choice of power supplies. High power PoE models deliver up to 60W of PoE per port.
Security and Quality of Service You Can Rely On
- The Aruba 2930M Switch Series includes security and quality of services (QoS) features to build a network that meets ever-changing corporate policies and compliances while protecting your data from both inside and outside attacks.
- Flexible authentication options include standards based security protocols such as 802.1X, MAC and Web Authentication, to enhance security and policy-driven application authentication.
- Powerful multilevel-access security controls include source-port filtering, RADIUS/TACACS+, SSL, port security, and MAC address lockout.
- Dynamic Segmentation provides user and port-based traffic tunneling to an Aruba Mobility Controller or Branch Gateway so that policies can be applied, advanced services can be extended to users and IoT devices, and traffic can be encrypted to protect the network.
Simplify with Integrated Wired/Wireless Management
- The Aruba 2930M Switch Series supports Aruba ClearPass Policy Manager for unified and consistent policy between wired and wireless users and simplifies implementation and management of guest login, user onboarding, network access, security, QoS, and other network policies.
- Aruba Airwave Network Management software provides an on-premise network management platform for wired and wireless network devices. Cloud-based management with Zero Touch Provisioning supported by Aruba Central.
- Supports both cloud-based Central and on-premise AirWave with the same hardware ensuring change of management platform without ripping and replacing switching infrastructure.
- RMON and sFlow provide advanced monitoring and reporting capabilities for statistics, history, alarms and events.
- Out-of-band Ethernet management port keeps management traffic segmented from your network data traffic.
Specifications
| TechnicalSpecifications | |
|---|---|
| Ports | (44) RJ-45 autosensing 10/100/1000 ports (4) Dual Personality 10/100/1000 BASE-T or 100/1000 Mbps SFP Ports (1) uplink module slot, (1) stacking module slot |
| Memory and processor | Dual Core ARM Coretex A9 @ 1016 MHz 1 GB DDR3 SDRAM Packet buffer size: 12.38 MB and 4.5MB Ingress, 7.785 Egress 4 GB eMMC |
| Latency | 1000 Mb Latency: < 3.1 µs 10 Gbps Latency: < 3.4 µs |
| Throughput | up to 112 Mpps |
| Switching capacity | 176 Gbps |
| Management features | Aruba AirWave Network Management Aruba Central IMC - Intelligent Management Center Command-line interface Web browser Configuration menu SNMP manager Telnet RMON1 FTP Out-of-band management (serial RS-232C or micro USB) |
| Power supply name | JL085A Aruba X371 12VDC 250W 100-240VAC Power Supply |
| Input voltage | 100 - 127 / 200 - 240 VAC, rated |
| Operating humidity range | 15 to 95% @ 104°F (40°C) (noncondensing up to 10000 ft) |
| Power consumption | 78W (maximim) |
| Heat dissipation | 185 BTU/hr 194 kJ/hr |
| Product dimensions (metric) | 4.39 x 44.25 x 32.43 cm |
| Weight | 4.60 kg |
